Safe and Efficient Loading Ramps for Light Equipment and Vehicles

LD5000 Series Portable loading Truck Ramp

The Adapt-A-Ramp LD5000 series truck ramp was designed to load small equipment onto the bed of customer pick up trucks. This truck ramp will improve worker safety by helping prevent injury and ensure efficiency by cutting your working time in half. An LD5000 Series Portable Ramp is ideal for loading lawn tractors, ATVs, motorcycles, and other light equipment into vehicles.

Features

Features Include:

  • Generous operating width.
  • Total Ramp stability.
  • Fully hinged deck & tail plate.
  • Easy height adjustment with the turn of a crank.
  • Rubberized 36” deep lip plate to protect tail-gates.
  • Non-slip deck surface.
  • Removable hand rails.
  • Built in fork pockets for easy movement.
  • Several safety features.

  • Deck and Tail Plate: 5’ wide x 14’ long

  • Hinged Lip Plate: 48” wide x 36” long

  • Height Range: 28” to 44”

  • Load Capacity: 5000 pounds

  • Safety Factor: 2 to 1

  • Hand Rails: 38” high x 120” long

  • Weight: 2400 pounds

  • Construction: Steel

Specs and Configurations

LD Series Light Duty Truck Ramp Specifications

The LD5000 Series Portable Truck Ramp is also available in different height and width ranges for special applications like the loading and unloading of golf carts, or other motorized sports vehicles wider than 5 feet.

Why Use LD5000

Why Use an LD5000 Truck Ramp:

The LD5000 Portable Truck Ramps will dramatically improve the safety and efficiency of your small equipment loading operations. This light duty truck ramp was designed in response to safety concerns voiced by many equipment companies due to their use of unstable rail type ramp options. The LD5000 light duty loading ramp provides many features to ensure a safe and efficient loading process. Some of these features include: a 5000lb load capacity with a 2 to 1 factor of safety, handrails, and anti slip steel grating along the deck of the ramp.

LD5000 Series Portable Truck Ramp Outside
Portable Loading ramp for pickup trucks feature 2-speed adjustable legs to make height adjustment fast and easy.

The two speed adjustable legs make height adjustment fast and easy

Adapt-a-Ramp portable dock ramps feature built in forklift pockets

The built in fork pockets make it easier to move the ramp around with a lift truck or loader

Portable loading ramps feature a rubberized lip bottom. LD5000

The rubberized lip bottom helps to protect your customers vehicles

Portable loading ramps by Adapt A Ramp feature a built in pocket design for fork lifts

The hinged tail plate improves stability of the ramp on uneven lot surfaces and also exposes the rear fork pockets

Portable Loading Ramps for pickup trucks featuring overlapping lip plates to protect your tailgate.

The overlapping lip plate extends onto the truck bed protecting the tailgate

Adapt A Ramp portable loading ramps featuring removable side rails

The hand rails improve operator safety and are removable when needed
